The Contest Contender

A Communicator Reprise: November 2014

For beginners… A look at the basics

While we have an active Contest Group at SARC, there are some within our membership who may not have been exposed to this activity. It is probably one of the most realistic scenarios for emergency operations training and a skill that any operator who has an interest in emergency preparedness should experience.

Contesting (also known as radiosport) is a competitive activity pursued by amateur radio operators. In a contest, an amateur radio station, which may be operated by an individual or a team, seeks to contact as many other amateur radio stations as possible in a given period of time and exchange information. Rules for each competition define the amateur radio bands, the mode of communication that may be used, and the kind of information that must be exchanged. The contacts made during the contest contribute to a score by which stations are ranked. Contest sponsors publish the results in magazines and on web sites.

Contesting grew out of other amateur radio activities in the 1920s and 1930s. As trans-oceanic communications with amateur radio became more common, competitions were formed to challenge stations to make as many contacts as possible with amateur radio stations in other countries. Contests were also formed to provide opportunities for amateur radio operators to practice their message handling skills, used for routine or emergency communications across long distances. Over time, the number and variety of radio contests has increased, and many amateur radio operators today pursue the sport as their primary amateur radio activity.

There is no international authority or governance organization for this sport. Each competition is sponsored separately and has its own set of rules.

Contesting Basics

Radio contests are principally sponsored by amateur radio societies, radio clubs, or radio enthusiast magazines. These organizations publish the rules for the event, collect the operational logs from all stations that operate in the event, cross-check the logs to generate a score for each station, and then publish the results in a magazine, in a society journal, or on a web site. Because the competitions are between stations licensed in the Amateur Radio Service (with the exception of certain contests which sponsor awards for shortwave listeners), which prohibits the use of radio frequencies for pecuniary interests, there are no professional radio contests or professional contesters, and any awards granted by the contest sponsors are typically limited to paper certificates, plaques, or trophies.

During a radio contest, each station attempts to establish two-way contact with other licensed amateur radio stations and exchange information specific to that contest. The information exchanged could include a signal report, a name, the U.S. state or Canadian province in which the station is located, the geographic zone in which the station is located, the Maidenhead grid locator in which the station is located, the age of the operator, or an incremental serial number. For each contact, the radio operator must correctly receive the call sign of the other station, as well as the information in the "exchange", and record this data, along with the time of the contact and the band or frequency that was used to make the contact, in a log.

A contest score is computed based on a formula defined for that contest. A typical formula assigns some number of points for each contact, and a "multiplier" based on some aspect of the exchanged information. The rules for most contests held on the VHF amateur radio bands in North America assign a new multiplier for each new Maidenhead grid locator in the log, rewarding the competitors that make contacts with other stations in the most locations. Many HF contests reward stations with a new multiplier for contacts with stations in each country - often based on the "entities" listed on the DXCC country list maintained by the American Radio Relay League ("ARRL"). Depending on the rules for a particular contest, each multiplier may count once on each radio band or only once during the contest, regardless of the radio band on which the multiplier was first earned. The points earned for each contact can be a fixed amount per contact, or can vary based on a geographical relationship such as whether or not the communications crossed a continental or political boundary. Some contests, such as the Stew Perry Top Band Distance Challenge, award points that are scaled to the distance separating the two stations. Most contests held in Europe on the VHF and microwave bands award 1 point per kilometer of distance between the stations making each contact.

After they are received by the contest sponsor, logs are checked for accuracy. Points can be deducted or credit or multipliers lost if there are errors in the log data for a given contact. Depending on the scoring formula used, the resulting scores of any particular contest can be either a small number of points or in the millions of points. Most contests offer multiple entry categories, and declare winners in each category. Some contests also declare regional winners for specific geographic subdivisions, such as continents, countries, U.S. states, or Canadian provinces.

The most common entry category is the single operator category and variations thereof, in which only one individual operates a radio station for the entire duration of the contest. Subdivisions of the single operator category are often made based on the highest power output levels used during the contest, such as a QRP category for single operator stations using no more than five watts output power, or a High Power category that allows stations to transmit with as much output power as their license permits. Multi-operator categories allow for teams of individuals to operate from a single station, and may either allow for a single radio transmitter or several to be in use simultaneously on different amateur radio bands. Many contests also offer team or club competitions in which the scores of multiple radio stations are combined and ranked.

If the foregoing has raised your interest in contesting and you would like to experience a contest first-hand, several members are willing to open their stations for you to give it a try. Contact a member of the Club Executive or send an email to communicator@ve7sar.net

~ John VE7TI

A Tale Of Two Hams

Radio Ramblings

This story appeared in the May Communicator [page 22] https://tinyurl.com/SARC19-5 and has had a positive response ao it is re-puplished here.

My wife Laura (VE7LPM) and I live in an old house on Smith Avenue in Burnaby.  In fact, I have lived there most of my life.  I came to the house in the summer of 1981 as a renter, and over the next few years was able to convince the owner to sell me the property.  It was expensive for a young police officer, but has turned out to be a good investment.  That aside, the place is centrally located near Boundary and Kingsway, and Laura and I have found it so convenient to practically everywhere that we have never thought too much about moving.  We respected the old place and have tried to keep it up.

Over the years the house supported all my amateur radio activities, my two towers, and a not insignificant antenna farm.  I participated in contests, deployed dozens of odd antennas, made my first satellite QSO from the back deck, completed DXCC, worked my first EME contacts, and even (literally) blew up my 2 kilowatt 2-metre linear there in 1989.  Ka-boom!

The house was built in 1925, and despite its age, it’s in pretty good shape.  See Figure 1.  I had some time in the past couple of months, so thought that I would do some investigative work to find out something of the history of our home as it approaches the end of its first century.

What I found is the subject of this month’s column.

Figure 1 – Our House Today

House Genealogy

All we knew about our house was that it was built in 1922  and that it had had a few owners before I moved in in 1981.  A retired police colleague had done research on his own house in Victoria, and suggested that a good starting point for finding out more is the “City Directory”.

City Directories were published annually and date from a simpler time where residents were not worried about financial scams or identity theft, and when privacy was not a significant social issue.  Directory representatives would visit all homes in the Lower Mainland (and the province) annually and gather details of residents, owners, and occupations of those living in the community.  The information was published in a thick large-format book indexed by streets and surnames.  Directories for all of BC going back to 1860 are now available online courtesy of the Vancouver Public Library (VPL)  .

I used the VPL site to research our house based first upon its address.  Strangely, I could find records of our home going back to the early 1960s, but for earlier years our address did not show up in the City Directories.  This was odd!

I had to try a different approach.  Each City Directory also indicates street and cross-street, so by looking at the combination of “Smith Avenue” and looking for cross street names, I learned that sometime in the late 1950s the block numbers in Burnaby were all “reset” to match the block numbers used in the City of Vancouver.  I confirmed this renumbering by referring to historical street maps .  I could not find our house prior to about 1960 because the house number had been changed!

Armed with the new block number (the 3800-block rather than the current 5400-block), I was then able to track our home and its owners/residents back to 1925.  Prior to 1925, there were no records.  This too seemed odd.  I discovered through inquiries at Burnaby City Hall that our home had been built not in 1922, as Laura and I had always thought, but rather, in 1925.  This was our first interesting discovery.  City Directory searches confirmed that a new house and new residents showed up at 3854 Smith Avenue in 1926.

By googling our old street address, I was amazed to discover that City of Vancouver Archives  had a photograph of our house in 1931 .  See Figure 2.  I deduced through some online research in the Vancouver Archives and some corresponding VPL information that our home had been photographed as part of an advertising program for a 1930s-era furnace company.  Somehow the photos had been preserved.  Very interesting!

Figure 2 – Our House on July 21, 1931

Back to the City Directories, I was able to track the owners and residents of our house from 1926.  Armed with resident names, I was able to cross-reference from the street index to the directory’s name-based entries and find out about occupations and businesses that the residents had been involved in.

This was interesting and I was able to build a chronology of owners and residents.  Laura and I are the sixth family to live here.  I googled the past residents, their occupations and businesses and discovered that prior to 1946 the house had been owned by a fellow who was involved in the auto business; and next by a large family who also owned another house on the block.  One of their daughters attended UBC.

I learned that in 1946 the house had been sold to a fellow named Edward James Fowler.  Naturally, I thought I’d do a bit of research on Mr. Fowler as I had on the other owners of our home.  See Figure 3.

Figure 3 – City Directory for 1946, “F. Fowler”

Serendipity

Googling “E.J. Fowler” and our old address, I discovered that Edward James Fowler was known as “Ted”, and that he was, in fact, VE7VO.  Ted Fowler was a very well-known personality in the local amateur radio community.  He had been in Vancouver since at least the late 1930s .

A prolific contester and DXer with several awards, he had been written of in QST and “Shortwave Magazine”, another popular radio magazine of the 1930s and 1940s.  This was very interesting!

See Figure 4 for a photo I found in the BC DX Club Archives of VE7VO and colleagues at the 1958 DX Convention in Vancouver .

Figure 4 - DX Convention, Vancouver 1958

Spurred to do further research, I next discovered that all of the old Radio Amateur Callbooks from the 1920s onwards  have been scanned and made available by the Internet Archive  – an excellent site for information on radio and television history and on old radio technology.

I downloaded several callbooks from the late 1940s and 1950s and looked up VE7VO.  See Figure 5 for VE7VO’s entry in the Fall 1947 callbook.  Note his address is that of our house at (then) 3854 Smith Avenue, shown as “New Westminster” rather than in Burnaby.

Figure 5 – VE7VO in the Fall 1947 Radio Amateur’s Callbook

I thought next that I would track VE7VO backwards from his purchase of our house in 1946.  I learned two more interesting things.  First, the VE7 call district did not exist prior to 1939.  This was news to me!  By searching for “Fowler” in the 1939 Callbook  I learned that VE7VO was in fact VE5VO at that time, but that he was already in Vancouver, as shown in Figure 6.

Figure 6 – VE7VO was VE5VO prior to WW II

The second thing I learned is that Mr. Fowler was a commercial pilot, as I am.  Unlike me, however, he had military flying experience.  I decided to follow this lead.

VE5VO had served with distinction in the Royal Air Force in Britain during the war.  As a pilot he flew several missions over Europe, and then after cessation of the war had been part of the RAF’s mission to disarm the German Luftwaffe.  “Shortwave Magazine” included a story in April 1946 about how Flight Lieutenant Fowler, VE5VO was instrumental in restarting amateur radio in Europe post-war .  He was issued the callsign D2VO.  See Figures 7 and 8.

Figure 7 – Shortwave Magazine, April 1946

Figure 8 – D2VO in Summer 1946 Radio Amateur’s Callbook

Post-war, Mr. Fowler was listed in the City Directory as a pilot and technician for TCA: Trans Canada Airlines, the forerunner of Air Canada.  However, I determined that he had changed careers by the 1950s and was involved in technical management of commercial radio transmitters .  He moved to Surrey in the early 1960s and passed away in 1983.  He was survived by a son, but there is no record of his son having an amateur radio license .


Other Interesting Observations

VE7VO lived in our house for about fifteen years, until about 1960.  He was active in amateur radio at that time.  I started thinking about whether I could find evidence of where his shack was, or perhaps where his antennas had been located.

When I moved into the house in the summer of 1981, I noted that one of the basement window frames had a number of strange large holes drilled in a linear fashion in its bottom frame.  I plugged the holes to keep mice and insects out, and eventually the window itself got replaced.  Now I am thinking that these holes were likely the ingress points for feedlines.  I had had evidence of “hamming” right before my eyes but had missed it!

A few years ago, Laura and I were doing yard work, as couples do.  She was digging up a rough patch in the backyard to smooth it out, and unearthed a large turnbuckle.  It was about a foot long and encased in rust.  She showed me the turnbuckle and I remember thinking “hmmm, when it was new that would’ve been great for securing a tower guy line”.  I didn’t recall losing a turnbuckle for my own towers, which were up at the time, but never really thought more of it.  The turnbuckle got tossed into our metal recycling.  Perhaps this was a leftover from one of VE7VO’s antennas.

The only other further evidence I have of antennas or antenna supports is weak, but I will present it here as it highlights another valuable resource for people doing historical amateur radio research.  Many cities have begun to make archival aerial photos available to the public.  These photos are integrated with modern GIS (Geographical Information Systems) and typically made available online.  Burnaby is no exception.

I visited the City’s “Burnaby Historical Aerial Photo Viewer”, which contains zoomable orthophotos of Burnaby going back to 1930 .  Heading back in time to 1930, I was able to look at our house and the neighbourhood and watch it develop over the subsequent decades.  In particular, I noted that my then-state-of-the-art “TH6” Yagi antenna was clearly visible in photos from the 1980s to the early 2000s.  See Figure 9a and 9b.  As an aside, note how the quality of these photos has improved due to advances in technology.

Maybe I could use historical orthophotos to find evidence of an antenna or tower!

 

Figure 9a – VE7ZD’s (VE7CPT’s) TH6 Yagi in 1985

Figure 9b – VE7ZD’s (VE7CPT’s) TH6 Yagi in 2004



























I turned next to orthophotos from the VE7VO period, 1946 to approximately 1960.  While I could not find obvious evidence of an antenna, I did note, however, the presence of an odd structure in the backyard of the house that cast a long shadow relative to other elements in the picture.  The photo is quite grainy, but you can make things out.  See Figure 10.

Figure 10 – House and Possible Antenna Support Structure in 1950

A tower or antenna support pole?  I will likely never know, but the structure’s location and characteristics do not look like a fountain, table, or other common garden element.  There is no evidence of the structure in our backyard today.

Interestingly, the structure was within about two metres of where I placed my own tower base in late 1981 after I moved into the house.  If the structure in the 1950 orthophoto was a tower or antenna support, it shows that hams even across time think alike!

Conclusion

This was an interesting journey into amateur radio history, and the history of one radio amateur, and his residence in the period from 1946 through about 1960.  I found out a lot about the history of our home, and located a fantastic 1931 photo of our house, showing it to be in essentially the same condition as it was nearly ninety years ago.

It was amazing to think that another ham, and such a prominent one, had lived in the same house as Laura and I, and that VE7VO and I have both enjoyed the challenges and thrills of amateur radio from this location.  I wonder if we chose the same room for our shack?

An ongoing project for me is to try and find an old QSL card from VE7VO, or even VE5VO .  QSLs usually give the op’s address and often list station details and other information which would be of great interest to me.  It would be really neat if VE7VO’s QSL included a photo of his QTH, or of his shack!

One final point.  In the late 1970s and early 1980s, I was extremely active on the bands, and was a member of a couple of local radio clubs, including the “Fraser Valley DX Club”, FVDXC.  We met in Surrey and Langley on a monthly basis.  I do not recall ever meeting Ted Fowler, VE7VO, but it is possible that, as a prominent DXer (then with decades of experience) and a then-Surrey resident, that he might have been a member of the FVDXC as well.  If he was, then I wish I had met him, and that the fact that serendipity had led me to live in his old home had come to light.  We would have had a lot in common, and meeting him would have been a really interesting experience!

That’s it for this month!  Feedback can be directed to the Editor, or directly to me at mcquiggi@sfu.ca.  Have a great month and 73,

~ Kevin VE7ZD / K7MCQ


Follow Kevin's "Radio Ramblings" monthly column in The Communicator

This article first appeared in the May 2019 SARC Communicator newsletter https://ve7sar.blogspot.com/2019/05/the-may-2019-communicator.html

The May 2019 Communicator

Projects, News, Views and Reviews...

Here is the May SARC Communicator newsletter: https://tinyurl.com/SARC19-5    This month just short of 60 pages of projects, news, views, and reviews from the SW corner of Canada.

https://tinyurl.com/SARC19-5

As always, thank you to our contributors, and your feedback is always welcome.  My deadline for the next edition is May 21st.

If you have news or events from your Vancouver area club or photos, stories, projects or other items of interest from elsewhere, please email them to the communicator@ve7sar.net

As always, thank you to our contributors, and your feedback is always welcome. My deadline for the next edition is April 21st.

If you have news or events from your Vancouver area club or photos, stories, projects or other items of interest from elsewhere, please email them to communicator@ve7sar.net

73,

John VE7TI
'The Communicator' Editor

Women in Radio

Hedy LaMarr

Hollywood Screen Seductress and the Mother of Spread Spectrum Communications

Other than some fleeting familiarity with her films, I first learned about Hedy Lamarr (9 Nov 1914 – 19 Jan 2000) while on a tour of celebrity homes in Palm Springs, CA. She was an Austrian actress, sex symbol and… yes, inventor. Not something usually attributed to screen seductresses.


She started her film career in Austria. When she worked with Max Reinhardt in Berlin, he called her the "most beautiful woman in Europe" due to her "strikingly dark exotic looks", a sentiment widely shared by her audiences and critics.  Friedrich Mandl, her first husband, objected to what he felt was exploitation of his wife. The 19-year old Lamarr had married Mandl on 10 August 1933. Mandl, reputed to be the third richest man in Austria, was a munitions manufacturer. In her autobiography ‘Ecstasy and Me’, Lamarr described Mandl as extremely controlling, preventing her from pursuing her acting career and keeping her a virtual prisoner, confined to their castle home, Schloss Schwarzenau. Although half-Jewish, Mandl had close social and business ties to the fascist governments of Italy and Germany, selling munitions to Mussolini.

In her memoir, Lamarr wrote that Mussolini and Hitler had attended lavish parties hosted at the Mandl home. Mandl had Lamarr accompany him to business meetings where he conferred with scientists and other professionals involved in military technology. These conferences became Lamarr's introduction to the field of applied science and the ground that nurtured her latent talent in the scientific field. She had been an excellent student and attended the best private schools in her youth.

Lamarr emigrated from Austria by posing as a maid, to escape her controlling husband. First she went to Paris, then met Louis B. Mayer in London. Mayer hired her and insisted that she change her name to Hedy Lamarr—she had been known as "the Ecstasy lady" — choosing the surname in homage to the beautiful silent film star, Barbara La Marr, who had died in 1926 from tuberculosis. She received good reviews for her American film debut in Algiers (1938) with Charles Boyer, who asked that Lamarr be cast after meeting her at a party.

She became a contract star of MGM's "Golden Age”.  In Hollywood, she was invariably cast as the archetypal glamorous seductress of exotic origins. Lamarr played opposite the era's most popular leading men during the 1940s. She appeared only sporadically in films after 1950, and for a time gave up custody of her children as she became destitute. Twice during the 1960s she was charged with shoplifting.

And now the rest of the story…

Avant garde composer George Antheil (died 1959), a son of German immigrants and a neighbor of Lamarr in California, had experimented with automated control of musical instruments, including his music for Ballet Mécanique, originally written for Fernand Léger's 1924 abstract film. This score involved multiple synchronized player pianos playing simultaneously.

During World War II, Antheil and Lamarr discussed the fact that radio-controlled torpedoes, while important in the naval war, could easily be jammed by broadcasting interference at the frequency of the control signal, causing the torpedo to go off course. Lamarr had learned something about torpedoes from Mandl. Antheil and Lamarr developed the idea of using frequency hopping to avoid jamming: using a piano roll to unpredictably change the signal sent between a control center and the torpedo at short bursts within a range of 88 frequencies in the radio-frequency spectrum (there are 88 black and white keys on a piano keyboard). The specific code for the sequence of frequencies would be held identically by the controlling ship and in the torpedo. It would be practically impossible for the enemy to scan and jam all 88 frequencies, as this would require too much power or complexity. The frequency-hopping sequence was controlled by a player-piano mechanism, which Antheill had earlier used to score his Ballet Mecanique.

On August 11, 1942, U.S. Patent 2,292,387 was granted to Antheil and Hedy Kiesler Markey, Lamarr's married name at the time. This early version of frequency hopping, although novel, soon met with opposition from the U.S. Navy and was not immediately adopted although it was held a closely guarded technological secret by the US military. Lamarr wanted to join the National Inventors Council but was reportedly told by NIC member Charles F. Kettering and others that she could better help the war effort by using her celebrity status to sell War Bonds.

Frequency Hopping was not implemented in the US until 1962, when it was used by U.S. military ships during a blockade of Cuba after the patent had expired. Her work was not honoured until 1997, when the Electronic Frontier Foundation gave Lamarr a belated award for her contributions. In 1998, an Ottawa wireless technology developer, Wi-LAN Inc., acquired a 49% claim to the patent from Lamarr for an undisclosed amount of stock. LaMarr was once again a wealthy woman.

Lamarr's and Antheil's frequency-hopping idea serves as a basis for modern spread-spectrum communication technology, such as Bluetooth, COFDM (used in Wi-Fi network connections), and CDMA (used in some cordless and wireless telephones).

For more on Hedy LaMarr, watch this YouTube clip:
https://www.youtube.com/watch?v=_rlXHNeQD-s

~ John VE7TI

Still Puzzled About HF Propagation?

Deciphering a Propagation Report

Richard VE2XIP has an informative blog on a variety of Amateur Radio subjects. Among the areas he covers is a very good primer on HF Propagation. I know this subject can be a difficult one to grasp, especially for beginners—even the more experienced have challenges in this area.

Richard writes:

“The very first thing I noticed when I got interested in propagation was a vast number of websites displaying charts and grids related to HF propagation conditions, but I didn’t really understand them at first. There are more types of measurements about the Sun’s activities than most care to understand, but there are a few ones that are very important to learn if you want to be able to understand a propagation reports.”

Have a look at the document. It’s at URL: https://www.qsl.net/co8tw/Understanding%20HF%20propagation.pdf

About Dummy Load PCBs and Oil

A Communicator Reprise: October 2014

Make a quick test to see if there is a problem

I picked up on a recent story that had some local input:

A while ago I bought an old Heath dummy load... full of oil. My main concern was whether the oil in it contained PCB's. Being an  older item I couldn't be sure. Since there is no way to tell by colour or odour I decided to research it further. What I found was a couple of simple tests that don't require any special equipment or chemicals and any one can do at home.

The first test is for PCB's in the oil, called a density test. Put a few drops of the oil in question in a glass of water. If the oil floats or spreads out on the top of the water it's free of PCB's. If it sinks then the oil contains PCB's. Since PCB's are heavier than water they will sink. Mineral oil is lighter and will float. However if any are detected this test doesn't tell the concentration amount.

The second test is a chlorine presence test. This test checks for chlorine in the oil to determine PCB presence.

This test is done by taking a piece of copper wire, dipping it into the oil and holding the wire over a flame such as a propane torch. Observe the color change of the flame. If the flame starts to turn green or blue green then PCB's are present. If the flame remains orange none are present.

The oil in my dummy load passed both tests. I changed it anyway because it smelled funny.

I can remember back when car AC systems were leak tested with a propane flame on a special wand. If the flame turned green, you were close to the leak area. I would imagine since refrigerant oils back then contained PCB's the same type of test was used. Later replaced by putting dye in the system and checking with a UV lamp.

So if any one ever wanted to know what might be in that old dummy load you brought back from the ham fest now is you chance to satisfy your curiosity.

The North Shore Amateur Radio Club also ran an article in their newsletter. Our own John Brodie VA7XB responded:

"In my previous job, I dealt with many PCB issues over the years.
PCB is heavier than water, so a drop of it in water will sink, unlike mineral oil. That makes for a pretty simple test to determine if it is PCB or not.
PCB is only “carcinogenic” in the sense that 50% of all chemicals, man-made or natural, are “carcinogenic” under extreme laboratory conditions which have little or no relevance to real life.

At BC Railways, we usually took our PCB  containing transformers and oil-filled capacitors to Powertech labs (an offshoot of BC Hydro) they had a process for destroying it."

John White VA7JW adds:

"You are not supposed to use motor oil as it is not made to have electrical insulating properties, probably has a low flash point, is flammable, and “sticky" which is not wanted either."

With thanks to WB2NGX, John Brodie VA7XB and John White VA7JW, who wrote an excellent article on the topic: http://www.orcadxcc.org/content/cantenna_va7jw.pdf

Can Shortwave Radios Detect Earthquakes?

A New Tool To Assist Earthquake Prediction?

The RF Seismograph: Another Exciting Amateur Radio First

Alex Schwarz VE7DXW, presented his findings at the SARC April 2019 monthly general meeting. Alex is exploring the possibility that “RF signatures” detected by the RF Seismograph propagation tool could also be indicating earthquakes, and may even be able to predict them shortly before they occur; one or two hours appear likely. A real-time HF propagation-monitoring tool developed by Schwarz and the MDSR team, the RF Seismograph shows both band noise and activity or band activity alone on six HF bands. It’s a project of the North Shore Amateur Radio Club (NSARC).

It has been documented for some time that major geological movements create magnetic waves. These magnetic waves interact with RF and manifest themselves as disturbances that are received on HF. Alex had been monitoring propagation intending to study the effects of the last solar eclipse. His finding showed a correlation with earthquake activity and the RF Seismograph was born. Basically, this is a broadband HF receiver monitoring a large range of frequencies.

The RF-Seismograph’s recent discovery that Earthquakes can be detected using a RF-receiver are intriguing and it validates a lot of new research that claims that earthquakes also create a magnetic field that extends into the Ionosphere and causes changes that can be measured with a cluster of GPS receivers.

The RF-Seismograph team has been collaborating with Earthquakes Canada to find a correlation between HF propagation and earthquakes. There was a distinct event that occurred on Nov 1st  (M5.0 off the coast of Vancouver Island) which was detected by the RF-Seismograph an hour before. Of course an hour warning before a major earthquake is significant.  There is process underway to correlate earthquakes that are bigger than M6.0 with the 4 years of data accumulated so far.

“We had been doing the solar eclipse experiment, and we developed the RF Seismograph software to look for changes in propagation during the eclipse,” Schwarz explained. “After the eclipse, we decided to leave the RF Seismograph running, and we have now collected 4 years of data.”

The system uses an omnidirectional multiband antenna to monitor JT-65 frequencies (±10 kHz) on 80, 40, 30, 20, 15, and 10 meters. Recorders monitor the background noise and display the result in six color-coded, long-duration graphs displaying 6 hours of scans. When signals are present on a band, its graph trace starts to resemble a series of vertical bars.

Most recently, the RF Seismograph recorded the magnitude 7.5 earthquake in Ecuador on February 22. Schwarz recounted that noise on 15 meters began to be visible about 1 hour before the quake; then, 2 hours after the quake released, 15 meters started to recover. The US Geological Survey said the quake was about 82 miles below ground. It did not affect 80 meters. Schwarz speculated that the quake was easy to see on the RF Seismograph because 15 meters typically is not open during hours of darkness — especially when the solar flux is only 70

Following a magnitude 5.0 earthquake off the coast of Vancouver Island, his RF Seismograph picked up changes. Canada’s government-run Earthquakes Canada was able to provide Schwarz with a list of magnitude 6.0 or greater events since the RF Seismograph went into operation, and the two teams have been collaborating to find a correlation between HF propagation anomalies and earthquakes. With the measurements, Schwarz has been attempting find a correlation between the list of past geological events and what his RF Seismograph may have sensed on those occasions.

“The earthquakes show up as RF noise because of the electric field lines, now scientifically confirmed to change the way the ionosphere reflects RF,” Schwarz said. He cited an article in the October 2018 edition of Scientific American, which, he says, “explains it really well.” (See Erik Vance’s “Earthquakes in the sky,” Scientific American, October 2018, p. 44).

The Scientific American article explores measurements in Japan looking into how earthquakes can create electric field lines that extend into the atmosphere. “Could they be used to detect earthquakes before they cause damage on the planet?” Schwarz asks.

Schwarz said 171 earthquakes — all magnitude 6.0 events or greater — were studied, and only 15 of them had no RF noise associated with them. In 26 cases, the time of the disturbance detected by the RF Seismograph failed to match the USGS-reported time of the quake. The latter likely because of the current low solar cycle and poor propagation.

Schwarz said that in 72% of the earthquake studies, the RF Seismograph was able to detect an increase in noise on 80 meters, typically before and after the event.

“More analysis is needed,” Schwarz has concluded. “The study is still continuing and we need your help to set up more monitoring stations.”

RF Seismograph is now a project on Scistarter.com, facilitated through Arizona State University. Schwarz said Scistarter hosts “interesting projects for all ages and backgrounds” and “provides a vehicle for young people that are interested in science to get real live experience in this field.”


Contact Schwarz for additional information.

A video of Alex's presentation is available at: https://youtu.be/Wz0ZkWXkIow

The presentation slides are at: http://nsarc.ca/wp-content/uploads/2019/04/RF-Seismograph-detects-Earthquakes-Markup.pdf

Alex’s site: http://users.skynet.be/myspace/mdsr/index.html

Partial post content courtesy of http://www.arrl.org/news/ve7dxw-s-rf-seismograph-may-be-real-seismograph
